Schneider Electric LP4K1210EW3 LP4K Series Contactor, 12 to 20 A, 3NO-1NO contact, 3 poles
Sku #38911085702
MFG #LP4K1210EW3
Attributes
| Type: | Contactor |
| Maximum Load Current: | 12 to 20 A |
| Frequency Rating: | 50/60 Hz |
| Series: | LP4K Series |
| Number of Poles: | 3 |
| Contact Configuration: | 3NO-1NO |
- TeSys K contactors and overload relays are ideal for general duty applications where small size and reliability are key concerns
- A The special armature structure design allows all devices and all operating coils, either AC or DC, to have the same physical size and panel footprint for convenience
- Devices are available with low consumption DC operating coils for direct connection to PLC circuits
- Resistive loadMotor control contactor application
- Built-in bidirectional peak limiting diode suppressor coil technology
- Power circuit 600 V UL 508Power circuit 690 V IEC 60947-4-1Signalling circuit 690 V IEC 60947-4-1Signalling circuit 690 V IEC 60947-5-1Signalling circuit 600 V UL 508Power circuit 600 V CSA C22.2 No 14Signalling circuit 600 V CSA C22.2 No 14 ui rated insulation voltage
- 8 kV uimp rated impulse withstand voltage
- III overvoltage category
- V1 conforming to UL 94Requirement 2 conforming to NF F 16-101Requirement 2 conforming to NF F 16-102 flame retardance
- 3 mOhm - Ith 20 A 50 Hz power circuit average impedance
- 10 to 20 ms coil de-energisation and NO opening 30 to 40 ms coil energisation and NO closing operating time
- B10d = 1369863 cycles contactor with nominal load EN/ISO 13849-1B10d = 20000000 cycles contactor with mechanical load EN/ISO 13849-1 safety reliability level
- 30 Mcycles mechanical durability
- 6561.68 ft (2000 m) without derating operating altitude
- With toxic heavy metal free
- Resistive load,Motor control
- CSA|UL Listed|PROP65: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
