Schneider Electric TeSys™ D LC1D09UD Non-Reversing IEC Contactor With Safety Cover, 250/690 V AC, 300 V DC V Coil, 25/9 A, 3NO Contact, 3 Poles
Sku #38911035368
MFG #LC1D09UD
Attributes
| Type: | Non-Reversing |
| Coil Voltage: | 250/690 V AC, 300 V DC |
| Coil Power Rating: | 7-1/2 hp at 575/600 VAC |
| Series: | LC1D |
| Maximum Load Current: | 25/9 A |
| Number of Poles: | 3 |
- Designed to control and provide overload protection to motors rated up to 100 hp at 480 VAC or 125 hp at 600 VAC, TeSys™ D meets your needs for a majority of motor starter applications
- New TeSys™ D green increase TeSys™ D range with a new electronic coil with up to 80% less consumption than TeSys™ D standard AC or DC coil
- TeSys™ D green contactor simplify your maintenance services with 90% less references needed
- TeSys™ D green contactor associated with TeSys™ LR9D electronic overload relay reduces heat generation and energy consumption up to 50%
- High fault short circuit current ratings provide the flexibility to select any component, as long as it meets or exceeds the desired SCCR
- All contactors include built-in auxiliary contacts
- All screw connections have IP20 finger safe terminals with both North American and international terminal markings
- Designed for perfect integration in control systems
- Can be used to create motor starters for any type of application
- 250 VDC, power circuit, 690 VAC at 25 to 400 Hz power circuit, 300 VDC
- 1 hp at 230/240 VAC 50/60 Hz 1-phase, 2 hp at 200/208 VAC 50/60 Hz 3-phase, 2 hp at 230/240 VAC 50/60 Hz 3-phase, 5 hp at 460/480 VAC 50/60 Hz 3-phase, 7-1/2 hp at 575/600 VAC 50/60 Hz 3-phase, 0.33 hp at 115 VAC 50/60 Hz 1-phase, built-in bi-directional peak limiting diode suppressor
- https://www.youtube.com/embed/ZspiS_-OK5U
- RoHS Compliant|WEEE Compliant|REACH Compliant|Green Premium|CCC Certified|CSA C22.2 No. 14|DNV Certified|EN 60947-4-1|EN 60947-5-1|IEC 60947-4-1|IEC 60947-5-1|UL 508|GoST-R Certified|RINA Certified|BV Certified|GL Certified|Lloyd's Register Certified|PROP65: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.p65warnings.ca.gov
- Industries, Infrastructure, Building, Resistive Load and Motor Control Applications
