Schneider Electric LC3D115P7A64, 230 VAC v coil, IP20 enclosure
Sku #38911020780
MFG #LC3D115P7A64
Attributes
| Voltage Rating: | 690 V AC |
| Frequency Rating: | 50 to 60 Hz |
| Coil Voltage: | 230 V AC |
| Amperage Rating: | 115 A |
| Motor Power: | 110 kw |
| Enclosure Type: | IP20 |
- motor control
- The TeSys D contactors and overload relays are the largest selling line of contactors and starters in the world
- They offer high reliability with long mechanical and electrical life and the most complete line of accessories in the industry
- TeSys D contactors are available in 11 contactor ratings for the USA market for inductive motor applications from 9 up to 150 full-load amps and resistive loads up to 200 amps
- Designed to control and provide overload protection to motors rated up to 100 HP at 480 VAC or 125 HP at 600 VAC, TeSys D meets your needs for a majority of motor starter applications
- New TeSys D Green increase TeSys D range with a new electronic coil with up to 80% less consumption than TeSys D standard AC or DC coil
- TeSys D Green contactor simplify your maintenance services with 90% less references needed.TeSys D Green contactor associated with TeSys LR9D electronic overload relay reduces heat generation and energy consumption up to 50
- High-fault short circuit current ratings provide the flexibility to select any component, as long as it meets or exceeds the desired SCCR
- Three levels of ratings: Available at 100 kA on systems with fuses, up to 600 volts
- Available at 65 kA on systems with circuit breakers, up to 480 volts and up to 32 amps
- Available at 100 kA on systems with circuit breakers, up to 480 volts and greater than 32 amps
- Eliminates the time-consuming process of selecting tested combinations through web sites and spreadsheets
- Simple to select the right product
- 3-pole and 4-pole contactor versions available
- All contactors include built-in auxiliary contacts
- All screw connections have IP20 finger-safe terminals with both North American and International terminal markings
- TeSys D contactors can be panel mounted with screws or DIN rail mounted
- Easily installed accessories
- Auxiliary contact blocks with serrated wiping action
- Front mount dust tight auxiliary contact blocks
- Pneumatic time delay blocks
- CSA|BV|GL|CCC|GOST|UL|Certified|DNV|LROS (Lloyds register of shipping) RINA|IEC 60947-5-1CSA|C22.2 No 14EN 60947-5-1UL|Certified|508EN 60947-4-1IEC 60947-4-1|CSA|BV|GL|CCC|GOST|UL Listed|Certified|DNV|LROS (Lloyds register of shipping)RINA|PROP65: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
