Sku #09596928867
MFG #FLUKE-1507
Attributes
| Voltage Rating: | 600 V AC/DC |
| Frequency Response: | 50 to 400 Hz |
| Resistance: | 0.01 Ohm to 20 kOhm |
| Amperage Rating: | 200 mA |
| Resistance Range: | 01 Ohm to 20 kOhm |
| Accuracy: | +/-2% +3 |
- For troubleshooting, commissioning and preventative maintenance
- Make repetitive tests simple and easy with the 1507's compare (pass/fail) function (only available on the 1507)
- Repetitive or hard to reach testing is easy with the remote test probe
- Live circuit detection prevents insulation test if voltage >30 V is detected for added user protection
- Auto-discharge of capacitive voltage for added user protection
- Save battery power with auto power off
- Read measurements easily with large, backlit display
- Cat IV 600 VAC overvoltage category rating for added user protection
- Remote probe, test leads, probes and alligator clips included with each tester
- Accepts optional Fluke® TPAK magnetic hanging system to free your hands for other work
- (4) AA alkaline batteries (NEDA 15 A or IEC LR6) for at least 1000 insulation tests
- Tester can perform at least 1000 insulation tests with fresh alkaline batteries at room temperature
- Tester can perform at least 2500 earth bond resistance measurements with fresh alkaline batteries at room temperature
- Discharge time < 0.5 s for C = 1 uF or less auto-discharge
- Remote Probe, Test Leads, Test Probes, Alligator Clips and User Documentation
- ANSI/ISA 82.02.01 (61010-1) 2004|CSA/CAN C22.2 No. 61010.1-04|ECCN 3A992|IEC/EN 61010-1|IEC/EN 61010-1 2nd Edition Cat IV 600 V|TUV Approved
- 1 year
