Littelfuse® SSAC® TCSHAB Adjustable Current Sensor Relay, 24 to 240 V AC, 2 to 20 A, 1NC 1 Form B SPST Contact
Sku #07945899944
MFG #TCSHAB
Attributes
| Type: | Adjustable |
| Voltage Rating: | 24 to 240 V AC |
| Sensor Type: | Toroid |
| Series: | TCS |
| Amperage Rating: | 2 to 20 A |
| Contact Configuration: | 1NC 1 Form B SPST |
- Self powered no control voltage is required to operate the unit
- Totally solid state and encapsulated no moving parts to arc and wear out over time and encapsulated to protect against shock, vibration and humidity
- Can connect directly to PLC solid state output to sink or source current can be connected directly to a standard PLC digital input module
- 1 A steady, 10 A inrush solid state output provide 100 million operations in typical conditions
- Complete isolation between sensed current and control circuit allows you to monitor a load in a separate electrical system
- CE Certified|UL Recognized|CSA Certified|PPROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer
