Littelfuse® SSAC® PLM9405 3-Phase Electro Mechanical Voltage Monitoring Relay, 480 V AC, 8 Pin, 1 Form C SPDT Contact
Sku #07945899793
MFG #PLM9405
Attributes
| Type: | 3-Phase Electro Mechanical |
| Voltage Rating: | 480 V AC |
| Contact Configuration: | 1 Form C SPDT |
| Series: | PLM |
| Frequency Rating: | 50/100 Hz |
| Number of Pins: | 8 |
- Quick octal 8-pin mounting small footprint with universal mounting ideal replacement for hundreds of competitive part numbers
- Proprietary microcontroller based circuitry, constant monitoring of 1-phase, low voltage, high voltage, voltage unbalance, phase reversal
- LED diagnostics, quick visual indicator for trip versus normal operation
- Isolated, 10 A, SPDT output contacts, allows control of loads for AC voltages
- Adjustable nominal voltage setpoint allows setting for specific application voltage to optimize protection
- Simple 3-wire connection for delta or wye systems, allows flexibility across wide range of systems
- ASME A17.1 rule 210.6 complies with safety codes for elevators, escalators, moving walkways
- NEMA MG1 14-30, 14-35 complies with safety codes for motors and generators
- IEEE C62.41-1991 level B complies with safety codes for surge and voltage protection
- CE Certified|UL Recognized|CSA Certified|ASME A17.1 Rule 210.6|NEMA MG1 14:30/14:35|IEEE C62.41-1991|PPROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer
