Littelfuse® SPD2-480-4P0 Type 2 CA Pluggable Surge Protection Device, 480 V AC, 50/60 Hz, 4 Poles, 25/50 kA SCCR
Sku #07945825779
MFG #SPD2-480-4P0
Attributes
| Type: | Type 2 CA Pluggable |
| Electrical Ratings: | 480 V AC |
| Number of Poles: | 4 |
| Series: | SPD2 4+0 Series |
| Frequency Rating: | 50/60 Hz |
| Short Circuit Current Rating: | 25/50 kA |
- Capability to clamp and withstand high energy transients - ensures low residual voltage during high energy surge events and higher nominal discharge current to prevent disruption, downtime and degradation or damage to equipment
- One component can be utilized globally, reducing inventory needs and simplifying allocation of parts
- Interlocking tab - mechanism secures module to withstand vibration
- No additional overcurrent protection devices required in UL applications - reduces the number of components and costs required for protection
- Compact footprint - increases panel design flexibility
- Visual life indicator - quick visual determines module replacement status to avoid loss of protection
- Pluggable modules - fast and simple to replace, minimizing maintenance and downtime, no tools required
- Thermal protection - eliminates catastrophic failure
- IP20 protection rating - finger safe design increases worker protection
- 25 kA/50 kA (IEC) and 200 kA (UL) short circuit current
- 2300 V (IEC)/1500 V (UL) Voltage protection
- Without neutral and remote contacts
- https://www.youtube.com/watch?v=5_pCwgWahZU&list=PL92CFB700D166068D
- cULus Recognized|CE Certified|E320116|IEC 61643-11:2011|EN 61643-11:2012|UL 1449|VDE/IEC Compliant
- For equipment protection from transient over voltages
