Littelfuse® SPD2-PV15-3P0 Type 2 CA Pluggable Surge Protection Device, 1500 V DC, 3 Poles, 9 kA SCCR
Sku #07945825754
MFG #SPD2-PV15-3P0
Attributes
| Type: | Type 2 CA Pluggable |
| Electrical Ratings: | 1500 V DC |
| Short Circuit Current Rating: | 9 kA |
| Series: | SPD2 PV Series |
| Number of Poles: | 3 |
| Clamping Voltage: | 4800 V |
- cULus Recognized|CE Certified|E320116|IEC 61643-11:2011|EN 61643-11:2012|UL 1449|VDE/IEC Compliant
- For equipment protection from transient over voltages and PV systems
- Capability to clamp and withstand high energy transients - ensures low residual voltage during high energy surge events and higher nominal discharge current to prevent disruption, downtime and degradation or damage to equipment
- No additional overcurrent protection devices required in UL applications - reduces the number of components and costs required for protection
- Compact footprint - increases panel design flexibility
- Visual life indicator - quick visual determines module replacement status to avoid loss of protection
- Pluggable modules - fast and simple to replace, minimizing maintenance and downtime, no tools required
- Thermal protection - eliminates catastrophic failure
- IP20 protection rating - finger safe design increases worker protection
- 9 kA (IEC) and 65 kA (UL) short circuit current
- Without neutral and remote contacts
- 4800 V (IEC)/4000 V (UL) Voltage protection
- https://www.youtube.com/watch?v=5_pCwgWahZU&list=PL92CFB700D166068D
