Littelfuse® POWR-GARD® LFJ60030-2CID Indicating Fuse Block, 600 V AC, 30 A, Class: J, 14 to 10 AWG Wire, 2 Poles
Sku #07945818177
MFG #LFJ60030-2CID
Attributes
| Type: | Indicating |
| Voltage Rating: | 600 V AC |
| Number of Poles: | 2 |
| Series: | LFJ |
| Amperage Rating: | 30 A |
| Class: | J |
- Space saving design upto 45% smaller than existing blocks
- Universal mounting holes for easy replacement
- Only 1-hand is required to release from DIN rail (lock open lock closed)
- Spring reinforced fuse clips are standard on 100 A and larger blocks, reinforcing springs are optional on 30 and 60 A blocks
- <0.6 mA at 600 VAC leakage current
- Lead-free
- Phenolic blocks have side barriers for isolation
- Indication offered on all versions except 200 to 600 A
- DIN rail releasable for all non-knife blade style fuses
- Covers available for 100 a and lower to enhance safety
- UL Listed|CSA Certified|UL 94 V-0 Flammability Rating|PROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer.
