Sku #07847794666
MFG #6H460-6Y
Attributes
| Type: | High-Flex UTP |
| Category Type: | CAT 6 |
| Conductor Type: | Stranded Copper |
| Series: | 6H460 |
| Conductor Size: | 28 AWG |
| Connector Type: | 8-Position Modular Non-Keyed Plug |
- For designed to be used in Cat 6/1 Gigabit applications and all frequencies from 1 to 250 MHz and high speed data applications
- Power over Ethernet (PoE and PoE+) compatible
- Accommodate use in high density switches, routers and other electronics
- Bend radius is a narrow 0.6 in, versus 1 in for typical Cat 6 Patch Cords
- Snagless plug design with integrated strain-relief boot
- Plug contacts rated to 2500 mating cycles
- Dual rated cable jacket (CM/LSZH)
- Supports 96 m channels that include 90 m permanent links
- Supports 93 m channels with 10 m of Patch Cords included in the channel
- 28 AWG stranded conductor cable for ultimate flexibility
- Narrow 0.15 in OD cable reduces airflow obstruction and maximizes cable management capacity
- Narrow profile plug to reduce congestion in high density applications
- Snag-free over molded boot design prevents boot from sliding on cable
- Under PoE at 90 W, maximum bundle size is 12 cables with a separation of 1-1/2 in from outer edge to outer edge of cable bundles for 28 AWG cables installed in air and a maximum ambient temperature of 113 deg F, as defined in TIA TSB-184-A
- ANSI/TIA-568.2-D/1096-A|Cisco UPoE+|FCC Part 68|IEC 11801-1|IEC 60332-1|IEEE 802.3bt/802.3af/802.3at|TIA TSB-184-A|UL 444|UL 94 V-0 Flammability Rating
