Sku #07847788273
MFG #1262
Attributes
| Type: | Grounding Momentary Contact |
| Amperage Rating: | 30 A |
| Contact Configuration: | SPDT |
| Voltage Rating: | 120/277 V AC |
| Power Rating: | 1/2, 2 hp |
| Contact Rating: | 1/2 hp at 120 V AC, 2 hp at 240 to 277 V AC |
- Positive switching action with center OFF position
- Large silver cadmium oxide contacts for long life prevent sticking, welding and excessive pitting
- Clamp type terminals accept up to 10 AWG copper wire
- Full rated current capacity on fluorescent, tungsten and resistive loads, motor load capacity up to 80% switch current rating
- 1/2 hp at 120 VAC, 2 hp at 240 to 277 VAC power rating
- Commercial Applications
- ANSI C73|NOM 057|Federal Specification WS896E File No. E7458|UL 20|UL94 V-2 Flammability Rating|CSA Approved
