Sku #07847784333
MFG #8450-IG
Attributes
| Type: | 3-Phase Extra Heavy Duty Isolated Ground |
| Amperage Rating: | 50 A |
| Number of Poles: | 3 |
| Voltage Rating: | 250 V AC |
| Horsepower: | 7-1/2 hp |
| Number of Wires: | 4 |
- Heavy gauge, double wipe copper alloy contacts
- Easy-to-wire terminals accept up to no 4 AWG conductors
- Terminals marked for easy identification and fast wiring
- All mounting hardware included
- Flush mount devices fit single or 2-gang outlet boxes
- Surface mount devices are commercial grade and have concentric knockouts for 3/4 and 1 in conduit and adjustable cord clamp for back and bottom entrance of cable
- 3-phase
- Maximum 30 deg C after 50 cycles OL at 150% rated current temperature rise
- Factories, Schools, Hospitals and Commercial Office Buildings
- NEMA WD1/WD6|ANSI C73|NOM 057|CSA C22.2 No. 42 File No. 152105|UL 498 File No. E13399|UL94 V-2 Flammability Rating
