Sku #07847783862
MFG #330C7W
Attributes
| Type: | North American Configuration Watertight |
| Voltage Rating: | 480 V AC |
| Frequency Rating: | 50/60 Hz |
| Series: | Series II |
| Amperage Rating: | 30 A |
| Number of Poles: | 2 |
- Industrial Applications
- Rugged housing, made of superior performance PBT, provides maximum corrosion protection and makes the device more resistant to impact, abuse and temperature extremes and V-0 flame rated and superior UV stability
- Watertight chloroprene onion skin grommet provides a precise, reliable seal at the cable entry point
- Rear terminals, raised lettering identification
- Calibrated, self-adjusting contacts
- Front terminals, raised lettering identification
- Rugged housing, provides maximum corrosion protection and makes the device more resistant to impact, abuse and temperature extreme
- Certified for current interrupting at full rated current
- Contact carrier resists arcing and internal heat build up
- Zinc-coated steel terminal screws on 20A and 30A devices
- Dependable, clean brass construction for long life, reliable electrical contact, maximum conductivity, and corrosion resistance
- Ground, neutral and phase terminals are clearly identified by color coding or letters and numbering on both front and back sides
- Multiple contact points assure a continuously reliable electrical connection
- CE 73/23/93/68/EEC|CSA C22.2 No. 182.1|IEC 60309-1/60309-2|UL 1682/1686|UL 94 V-2 Flammability Rated
