- Patented Retention Force Technology™ (RFT) protects against tine damage and increases system longevity
- For power over ethernet, RFT maintains contact force between plug and jack, preventing arcing from intermittent disconnects
- Shielding provides EMI/RFI protection, signal isolation and excellent alien crosstalk (AXT) suppression
- Unique design supports tool-free termination/re-termination and requires no specialized termination tool
- Short connector design supports a wide range of installation practices and improves bend radius of Cat 8 shielded cabling
- Robust IDCs can withstand 20 re-termination cycles and connector contacts are tested for 750 plug mating cycles to ensure system longevity
- Interchangeable icons (voice, data, A/V and blank, color coded to match the jack face) are available for easy identification and tracking of data, voice or other functions
- Solid metal body dissipates 53% more heat than plastic, minimizing damage from excess heat in PoE applications
- Tine geometry prevents arcing damage where plug and jack make contact
- https://www.youtube.com/embed/D5DVNjfJh7c
- Used to support next generation BASE-T data center networks
- ANSI/TIA-568.2-1|ISO/IEC 11801 Class I|cULus Listed|IEC 60603-7|IEC 60512-99-001|UL 2043|ANSI/TIA-1096-A|IEEE 802.3at Type 1 and Type 2|IEEE Draft 802.3bt Type 3 and Type 4
