- Provides continuous ground fault protection - detects and trips on actual ground fault even when self-test is being conducted
- On initial power up, tests the GFCI within 3 sec
- Auto-monitoring exceeds the UL requirement
- Auto adapts and shifts to more frequent testing if potential problem is detected
- Testing frequency regularly updates protection status
- Electronics are designed to minimize any false triggers
- Patented bridge contact provides individual sets of contacts for GFCI receptacle face and downstream receptacles no power will be delivered to receptacle face if improperly wired (line-load reversed)
- Trip threshold meets or exceeds UL requirements for tripping time
- Improved immunity to high frequency noise reduces nuisance tripping
- Advanced electronics design provides superior resistance to electrical surges and over-voltages
- Patented lockout action prevents reset if GFCI is damaged and cannot respond to a ground fault
- Status indicator light provides simple, intuitive feedback on power and protection status as well as indication of line/load reversal
- Silver alloy contacts
- 20 A feed-through current and impact-resistant thermoplastic cover and body
- One-piece T-design trip latch mechanism provides efficient operation
- Compatible with all Decora® devices and wallplates
- Withstands 2000 VAC per UL498
- 10 kA short circuit current rating
- Maximum 30 deg C after 100 cycles OL at 150% rated current temperature rise
- Rated V-2 per UL94 flammability
- https://www.youtube.com/embed/2i8vraBl5sw
- Residential, Educational Facilities, Airports, Restaurants, Lodging and Retail Malls, Commercial Offices and Public Areas Applications
- Nylon Wallplate/Faceplate, Screws and Self-grounding Clip
- ANSI C73|UL 498 File No. E13399|UL 943|UL File No. E48380|UL Federal Specification WC-596|CSA C22.2 No. 42|CSA File No. LR57811|NOM 057|NEMA WD6
- 2 Years Limited
