Sku #07847770507
MFG #ODC0P-D0W
Attributes
| Type: | Dimming Low Voltage |
| Sensitivity: | 32 to 1722 fc |
| Mounting Type: | Ceiling |
| Voltage Rating: | 12 to 24 V DC |
| Environmental Conditions: | 32 to 131 deg F Operating Temperature |
| Color: | White |
- Dimmed lighting at a desired daylight design level offers greater energy savings and comfort and improved energy efficiency
- Leviton® exclusive, patented auto-calibration eliminates the need for configuring labor costs during daylight harvesting configuration
- Industry exclusive fail safe circuitry in the event of product failure, return to closed feature causes the relay to default ON which eliminates life safety concerns
- Fade rate time setting 3 to 30 min
- Controls 1 to 10 VAC sinking ballast, no additional power supply required for 1 to 10 VAC sinking operation
- Dim to OFF over DDL for 30 sec then lights OFF, test mode 30 sec fade rate for 15 min then auto exit
- Provides ultra convenient, hands free lighting control
- Measures light from any source in the visible spectrum within a 60 deg cone at 8 to 12 ft H mounting
- Provides continual measurements to control the lighting
- Mounts on ceiling, surface mount or low profile flush mount
- LED status indicators for ease of installation
- ASHRAE 90.1|FCC Compliant|IECC Rated|Title 24 and NYCLL48|UL 916
