Sku #07847769998
MFG #61SJK-SO6
Attributes
| Type: | Component Rated |
| Mounting Type: | Surface |
| Color: | Orange |
| Module Type: | Cat 6 |
| Material: | Die Cast Zinc |
| Dimensions: | 0.9 in H x 1.31 in W x 0.68 in D |
- ANSI/TIA-568-C.2|cULus Listed|IEEE 802.3at|IEC 60603-7|IEC 60512-99-001|ISO/IEC 11801|UL 2043 Plenum Certified
- Independently tested and guaranteed to exceed all component, permanent link and channel margins
- Patented retention force technology (RFT) protects against tine damage from 4 or 6-pin plugs
- Shielding provides EMI/RFI protection, signal isolation and excellent alien crosstalk (AXT) suppression
- Unique design supports tool free termination/re-termination and requires no specialized termination tool
- Short connector design supports a wider range of applications (e.g. shallow boxes, enclosures, bend radius and more)
- Robust IDC's can withstand 20 re-termination cycles and connector contacts are tested for 750 plug mating cycles to ensure system longevity
- Connector supplied with interchangeable icons (voice, data, A/V and blank, color coded to match the connector face) for easy identification and tracking of data, voice or other functions
- Network Applications
