Sku #07847764267
MFG #O4C15-IDW
Attributes
| Type: | Dual Relay Line Voltage |
| Amperage Rating: | 30 to 60 mA |
| Coverage: | 1500 sq-ft |
| Voltage Rating: | 120/230/277 V AC |
| Sensor Type: | Multi-Technology/PIR/Ultrasonic |
| Viewing Angle: | 360 deg |
- Commercial Applications
- Auto-adapting time delay and sensitivity are continually adjusted to occupancy pattern of use
- Vacancy sensing timeouts delayed OFF timer, exclusive Walk-through feature, false detection timer (M/T) PIR scans for movement and shuts lights OFF after 31 min of vacancy preventing false triggers from HVAC systems (U/S)
- Time delay and saved settings are protected during power outages and will return to the last known state
- Industry exclusive self-configuring local manual switch input, momentary or maintained switches are supported
- Adjustable time delay 30 sec, 5 min, 10 min, 20 min and 30 min
- Test mode for simplified commissioning
- Manual switch and emergency override are class 1 and 2 circuits, class 2 circuits provided for flexibility
- Industry exclusive fail safe circuitry in the event of product failure, return to closed feature causes the relay to default ON which eliminates life safety concerns
- Industry exclusive HIS (high inrush stability) technology designed to handle today's high inrush electronic ballast loads and offer unmatched durability and service
- Robust and reliable mechanically held 10 A latching relay provides dependability and robust performance for all load types and provides energy savings over electronically held relays
- Lenses on PIR models are easily replaceable and color coded red (mid range) for contractors and end users to easily identify lenses from the ground
- Red blinks when infrared is detecting motion and solid during device malfunction, yellow blinks during test mode, solid with emergency/BMS input, blue blinks when knob settings are changed and green blinks when U/S is detected
- https://www.youtube.com/embed/jK48BrNhHBw
- UL 924|Title 24 Compliant|ASHRAE 90.1
