Sku #07847762249
MFG #AFRBF-W
Attributes
| Type: | Blank |
| Amperage Rating: | 20 A |
| Number of Poles: | 2 |
| Voltage Rating: | 125 V AC |
| Horsepower: | 1 hp |
| Number of Wires: | 3 |
- For use with circuits feeding lighting loads and/or other loads such as smoke detectors where a receptacle is not used
- 20 A, 125 VAC at feed-through switch rated
- Thermoplastic face brass double wipe line contacts, plated steel terminal and ground screw zinc plated steel yoke, brass clamp, galvanized steel strap
- Use of TEST and reset buttons is similar to traditional GFCI receptacles of which consumers have become familiar with, this translates into greater acceptance of the technology and a more user-friendly platform
- Automatically tests the GFCI every time the reset button is pushed in, the GFCI will not reset if the GFCI circuit is not functioning properly
- By blocking reset of the AFCI if protection has been compromised, the SmartlockPro® OBC AFCI reduces the possibility of end users incorrectly assuming that a reset AFCI is providing protection when its functionality has been compromised
- A line load reversal diagnostic feature is provided which prevents the AFCI from being reset and stops power from being fed to the AFCI receptacle face or through to downstream devices, a green LED indicator on the AFCI's face also illuminates to alert the installer to A-line load wiring reversal when the device is in the tripped state
- Device design reduces nuisance tripping
- Impact resistant thermoplastic cover and body
- Superior resistance to electrical surges and over voltages
- Terminals allow for easy wiring options - back and side wire capable
- Compatible with all Decora® devices and wallplates
- https://www.youtube.com/embed/RCcF6HGPaFo
- Mounting Screw, Self-Grounding Clip
- 2 Years
- UL/ CSA
