- PC and monitor modules must be used as a set (PC and monitor modules)
- Modules must be installed in a Leviton® MOS wallplate
- Modules are 1-unit high
- VGA modules can be mixed with other MOS modules in the same wallplate
- Two twisted pair cables (CAT 5e or higher, UTP or shielded) required for each set of VGA modules
- Not compatible with MOS surface mount boxes
- Provides a point to point VGA connection over twisted pair cabling (UTP or shielded)
- Passive modules compensate for the impedance difference between 75 Ohm unbalanced video signal and the 100 Ohm balanced cabling
- Twisted pair cabling provides a migration path for future digital signals
- Fast and easy cable termination using color coded 110 style IDC connectors
- Display Data Channel (DDC) signals included, which allow the PC to detect the displays capabilities
- Female-to 110-Style connector
- 32 to 122 deg F operating temperature
- 14 to 158 deg F storage temperature
- 0 to 90% relative humidity
- https://www.youtube.com/embed/gX99g5i0tGo
- Commercial Applications
- cULus Listed|CAN/CSA C22.2|No. 182.4-M90|TIA/EIA-568-B|UL 1863|UL94 V-0 Flammability Rating
