Sku #07847757491
MFG #AFTR1
Attributes
| Type: | Duplex Self-Grounding Tamper Resistant |
| Amperage Rating: | 15 A |
| Frequency Rating: | 60 Hz |
| Voltage Rating: | 125 V AC |
| Horsepower: | 1 hp |
| Number of Poles: | 2 |
- Use of test and reset buttons is similar to traditional GFCI receptacles of which consumers have become familiar with, this translates into greater acceptance of the technology and a more user-friendly platform
- Automatically tests the AFCI every time the RESET button is depressed, the AFCI will not reset if the AFCI circuit is not functioning properly
- TR symbol indicates the devices compliance with the latest NEC® requirements for tamper resistant receptacles in residences and childcare facilities
- Device design reduces nuisance tripping
- Impact resistant thermoplastic cover and body
- Superior resistance to electrical surges and over-voltages
- Terminals allow for easy wiring options - back and side wire capable
- Compatible with all Decora® devices and wallplates
- Meets or exceeds UL requirements for tripping time on both series and parallel arcs
- Packed with coordinating wallplate (except AFRBF)
- Expanded wiring options with nine back-wire holes (two for each line and load connection plus one for ground with an internal clamp)
- OBC AFCI receptacles address the dangers associated with both types of potentially hazardous arcing - parallel and series arcing
- Similar to GFCIs, AFCI receptacles provide feed-through protection and are able to detect downstream parallel and series arc-faults as well as upstream series arc-faults
- Dielectric voltage withstands 1250 VAC per UL 1699A
- Back and side termination
- 14 to 10 AWG terminal, tamper resistant
- By blocking reset of the AFCI if protection has been compromised, the SmartlockPro® OBC AFCI reduces the possibility of end-users incorrectly assuming that a reset AFCI is providing protection when its functionality has been compromised
- A line-load reversal diagnostic feature is provided which prevents the AFCI from being reset and stops power from being fed to the AFCI receptacle face or through to downstream devices a green LED indicator on the AFCIs face also illuminates to alert the installer to a line-load wiring reversal when the device is in the tripped state
- Nylon wallplate/faceplate
- Monochromatic
- https://www.youtube.com/embed/RCcF6HGPaFo
- Bedrooms, Closets, Dens, Dining Rooms, Dormitories, Family Rooms, Hallways, Living Rooms, Libraries, Parlors, Recreation Rooms, Sunrooms or Similar Areas
- ANSI C73|CSA C22.2 42|CSA Technical Information Letter M-02A|NOM 057|NEMA WD-6|UL1699.A E342815|UL498|UL Fed Specification WC-596
- Screws , Self-Grounding Clip
- 2 Years Limited
