Sku #07847754465
MFG #MDS15-IDI
Attributes
| Type: | 1-Pole Low-Profile Photocell Controlled Single Relay |
| Power Rating: | 100/277 mW |
| Coverage: | 2100 sq-ft |
| Voltage Rating: | 120/230/277 V AC |
| Sensor Type: | PIR |
| Viewing Angle: | 180 deg |
- Fits in standard wallbox and replaces 1-pole wall switch, gangable with other units, ground connection required
- Low profile design eliminates obtrusive scanning device look
- Elegant Decora® wallplates compliment any interior for sleek aesthetics, uses Decora® wallplates and coordinates with Leviton® popular line of Decora® wiring devices
- 180 deg field of view provides approximately 2100 sq-ft of coverage
- Convenient pushbutton provides manual ON/OFF light switching at any time
- Two dual element PIR sensors used to widen detection range
- Segmented fresnel lens provides optimum sensitivity and performance
- Designed with an extensive ''minor motion'' area where even slight body movements will be detected
- Vandal resistant PIR lens
- Lev-Lok® makes installation and replacement simple with latch and lock system which streamlines installation and reduces costs
- The Lev-Lok® wiring module is keyed so that it cannot be installed incorrectly, saving time during installation and making maintenance quicker, safer and easier
- Horizontal field-of-view may be adjusted between 180 and 60 deg of arc by using integral blinders located on either side of the lens, no masking tape required
- Manual ON/auto OFF mode for installations where manual ON switching is required but auto OFF switching is still desired for CEC title 24 energy savings
- Red LED indicator light flashes when sensor detects motion to verify detection is active
- Time delay in adapting mode, the time delay can be configured from 30 sec (test mode), 5, 10 and 20 min in non-adapting mode, the delay can be configured from 5, 10, 20 and 30 min
- Light sensor adjustable ambient light override ranges from approximately 20 to 5000+ LUX to prevent lights from turning ON automatically during periods of ample natural light, increasing energy savings
- Light sensor enables the load hold OFF feature once level has been set
- Vacancy confirmation when the time out expires and the relays turns OFF, a 30 sec vacancy confirmation exists to turn the relays back ON
- False detection circuitry
- Presentation mode feature for slide or film presentations allows pushbuttons to turn lights OFF and keep them OFF while the room is occupied
- https://www.youtube.com/embed/lWSqZ3i3_Ug
- UL/cUL Listed|CEC Title 24 Compliant|FCC/NOM Certified
- Small Office, Conference Rooms, Lounges, Classrooms, Private Restrooms, Heavier Loads, Storage Areas and Commercial Applications
