- Rotating light sensor optimal for best performance in locating light measurements (up, down and side lighting)
- Auto-calibration set to auto calibration, light sensor measures lowest light level of facility with all lights ON for 24 hr to determine the daylighting set point
- Manual calibration optimize energy savings and operation by manually configuring the daylighting set point
- Performance daylighting enhanced design algorithms to assure lights will not cycle during cloud cover or varying light levels
- Fast and simple setting the OSFHP does not require power to set the time delay saving valuable time during installation load 1 =30 sec to 30 min, load 2 =30 sec infinity (starts after load 1 expires)
- Fast and simple testing OSFHD will instant ON within 5 sec, upon initial power, relay is closed enabling labor savings testing in sec
- Power interruption state for energy savings and safety, if power is lost to device, device will return to last known state
- Fast, simple installation the OSFHP sensor easily installs on individual fixtures using standard 1/2 in knockouts and the quicksnap feature which eliminates the time to tighten the locknut
- The 42 in wire leads reduce time and materials for connecting the ballast
- Simply make the electrical connections inside the ballast compartment, install the appropriate adjustable lens assembly included and the sensor is ready
- Zero crossing circuitry relay uses a zero crossing circuitry to provide reliable, long life operation
- Range and coverage the 360 deg high bay PIR lens provides a 21 spacing to mounting height coverage under 25 ft mounting and a 1.51 for heights up to 40 ft mounting
- The 360 deg low bay lens provides 21 spacing to mounting height coverage for 8 to 20 ft mounting
- LED super bright green LED indicates occupancy detection and can be seen at 40 ft
- False detection protection energy saving technology is designed into the OSFHD to assure your lights are ON only when needed
- Warehouses, Manufacturing, Cold Storage, Other High Ceilings and Commercial Applications
- UL 916|CSA C22.2 No. 205 M1983|FCC Approved|Title 24 Compliant
