- Multi-location dimming locator indicator configurable cut-off level solid state triac dimming
- Remote dimmers and switches
- Connect up to 5 devices, maximum 250 ft on one traveler wire
- Remote control all connected master dimmers
- Masters always operate independently
- Locator indicator illuminates when dimmer is OFF for easy location in a dark room
- Non-neutral models for retrofit applications
- Configurable cut-off level allows user configuration of cut-off point and automatically recalibrates to allow maximum control from cut-off point to full output
- Smooth action, linear captive slide control easy, precise adjustment of lighting levels, easy touch preset switch turns lights ON at last selected brightness level
- Clean and stylish appearance fits standard commercial 2-1/2 in deep wallboxes, Decora® wallplates coordinate with Leviton® extensive line of Decora® devices, fins are easily removed for multi-gang applications, no visible metal heat sinks, fins or mounting hardware
- Solid state triac dimming saves energy when dimming, extends lamp life and reduces maintenance costs
- Flicker free, smooth and continuous dimming reduces light fluctuations from line voltage variation and maintains the power delivered to the lamp
- Power failure memory light is restored to the same levels set prior to the power failure or power interruption
- Surge protection tested to withstand surges of 6000 VAC, 200 A
- Electrostatic discharge protection protects dimmer against static discharge up to 16000 VAC
- Advanced technology engineered heat sinks transfers heat away from essential electrical components for extended product life
- Square law dimming slider position indicates the perceived light level
- RFI filtering reduces interference with radio, audio and video equipment
- Neutral required
- 0 to 10 VDC dimming capability
- Architectural Dimming Control and Multi-Gang Applications
- ANSI/IEEE C62.41.2|CSA File No. E31373/E123566|IEC 61000|FCC Part 15 Class B|UL/cUL/ETL/cETL Listed
