Sku #07847742563
MFG #ODD24-IDW
Attributes
| Type: | 1-Pole Smart Dimming |
| Voltage Rating: | 12 to 24 V DC |
| Sensor Type: | Passive Infrared |
| Series: | ODD24 |
| Amperage Rating: | 0.02 A |
| Coverage: | 1200 sq-ft |
- Can be used to comply with IECC, ASHRAE 90.1 and 2019 Title 24, Part 6 occupancy/vacancy sensing and dimming requirements
- 180 deg field of view provides approximately 1100 sq-ft of coverage
- Maximum sensing distance in front of the sensor is 30 to 40 ft and 15 to 20 ft on either side
- Advanced configuration can be performed using the Leviton® smart sensor App on any Bluetooth® enabled Android or iOS device: set operating mode to auto-on/auto-off or manual-on/auto-off
- Adjust the sensitivity of the sensor to increase or decrease coverage area, adjust timeouts, activate the nightlight and select nightlight colors, add daylighting hold-off and select target daylighting hold-off levels and set a security code to lock configuration settings
- Configure dimming options such as partial-on, partial-off and partial-off timeouts
- Out-of-the-box configuration default mode - auto-on/auto-off with 10 min time out
- Sensitivity set to 75%
- Nightlight and daylighting hold-off disabled
- https://www.youtube.com/embed/ydCw3ouKuLI
- Small Offices, Lobbies and Small Meeting Rooms Applications
- 2019 California Title 24, Part 6 Compliant|ASHRAE 90.1|cUL Listed|FCC Approved|ICC Certified|IECC Certified|UL Listed
