Sku #07847740790
MFG #49990-LSC
Attributes
| Type: | Anaerobic Adhesive Style |
| Connector Type: | SC |
| Cable Construction: | 50/125 um |
| Series: | 49990 |
| Fiber Type: | OM3/4 Laser Optimized Multi-Mode |
| Color: | Aqua |
- Low insertion loss connection
- Higher fiber retention than mechanical connectors
- No curing oven or proprietary tool required
- Compatible with MOS, QuickPort®, SDX and LightSpace® adapter plates
- Precision pre-radiused zirconia ferrules
- High cable retention crimp for jacketed fiber
- Recommended for indoor and outdoor usage
- Body of ST connectors are metal
- 0.2 dB typical and < 0.3 dB insertion loss
- > 25 dB typical return loss
- -40 to 85 deg C operating temperature
- Typical termination in <3 min
- Most robust connection
- 25 dB return loss
- -40 to 85 deg C temperature rating
- Commercial, Inside and Outside Plant Applications
- ANSI Specified|TIA-568-C.3|GR-326
