- Terminates 26 to 22 AWG solid conductor
- Capable of multiple re-termination
- Gastight IDC connectors prevent corrosion
- Dual layer T568B/T568A wiring label simplifies punchdown
- Patented retention force technology protects tines from damage and increases system longevity
- Pair separation tower design facilitates separation of conductors and minimizes untwisting
- 180 deg configuration allows for rear termination
- Terminates 26 to 22 AWG solid conductors
- Use in any QuickPort® housing to support eXtreme® Cat 5e UTP connectivity in surface-mount, flush-mount, or modular furniture outlets and field-configurable panels
- Can be used in conjunction with other QuickPort® snap-in modules for voice/data and video applications over UTP, coax, and fiber
- Connector body is high-impact, fire-retardant plastic rated UL94V-0
- High-quality copper-based alloy, plated with 50 micro-inches of gold over 100 micro-inches of nickel for lowest electrical contact resistance and maximum life
- -40 to 70 deg C storage and -10 to 60 deg C operating temperature
- Voice, Data and Video Applications
- ANSI/TIA-568-C.2|1096-A|cULus Listed|IEC 11801
