Sku #07847729751
MFG #49991-5SC
Attributes
| Type: | Pre-Polished |
| Connector Type: | SC |
| Cable Construction: | 50/125 um |
| Series: | 49991 |
| Fiber Type: | OM2 Multi-Mode |
| Ferrule Type: | Pre-Radiused Zirconia |
- Precision mechanical termination
- Fast and easy to install (<1 min)
- No polishing, epoxy curing, consumables
- No proprietary tools
- Low insertion loss connection
- Uses proven, molded V-groove technologies
- Higher yields with visual fault locator (VFL) compatible LC, SC and ST connectors
- 25 dB return loss
- -40 to 75 deg C temperature rating
- Fast and easy-to install (less than one minute)
- Allow optical continuity to be verified by use of visual fault locator (VFL)
- 900 um or 250 um buffered cable termination
- -40 to 75 deg C operating temperature
- 0.1 dB typical <0.5 dB max insertion loss, >25 dB return loss
- 0.35 in Dia x 2.08 in W
- ANSI/TIA-568-C.3/604-3|ISI 9001 Certified
- Commercial Applications
