Sku #07847728658
MFG #OSF10-I0W
Attributes
| Type: | Integral Luminaire |
| Power Rating: | 800/1200 VA |
| Coverage: | 10 ft |
| Voltage Rating: | 120 to 277 V AC |
| Sensor Type: | PIR |
| Time Delay: | 30 s to 30 min |
- Uses passive infrared technology to detect motion
- Time delay the time out occurs when motion is no longer detected by the sensor and the device counts a set amount of time before turning off the load
- If the device sensor detects motion during this 'time delay' the count resets and the device initiates a new count
- The time delay can be adjusted to 30 sec, 10, 20 and 30 min respectively
- Zero crossing circuitry relay uses a zero crossing circuitry to provide reliable, long life operation
- LED- a red LED blinks when motion is detected
- Fresnel lens detects small motion when mounted within 6 ft of occupants
- When mounted at a height of 8 ft, the coverage will be approximately 10 ft diameter but sensitivity may be diminished
- The field of view below shows maximum coverage
- Commercial Applications
- UL Listed|CSA Certified|Title 24 Compliant
