- Craft friendly installation
- Color coded front labeling for easy port identification
- Centralized labeling promotes greater visibility of labels when patch cords are routed into horizontal cable management above and below the patch panel
- Patented retention force technology protects tines from damage and increases system longevity
- Universal T568A and T568B wiring cards for 110 style IDC terminations
- Terminates 26 to 22 AWG solid conductors
- Capable of multiple reterminations
- Panel available with patented magnifying lens label holder for easy reading
- Mounts on 19 in equipment racks
- Panel offered in 12-, 24-, 48-, 96-port configurations and 12-port U89 block for wall-mount applications
- Connector modules are in groups of six
- Use star washers for grounding in rack-mount installations
- 14 ga steel, painted black, PCB and plastic components are rated per UL94V-0
- 2 rack unit
- 3.5 in H x 19 in W x 1.48 in D
- For 19 in rack, cabinet electronic equipment and high megabit applications
- Rear Cable Management Bar
- ANSI/TIA-568-C.2|ISO/IEC 11801|ANSI/TIA-1096-A|cULus Listed|IEEE 802.3at (Type 1)|IEEE 802.3at (Type 2)|IEEE 802.3bt/D1.7 (Type 3)|IEEE 802.3bt/D1.7 (Type 4)
