Sku #07847708580
MFG #49990-SST
Attributes
| Type: | Anaerobic Adhesive |
| Connector Type: | ST |
| Ferrule Type: | Pre-Radiused Zirconia |
| Series: | 49990 |
| Fiber Type: | Single-Mode |
| Material: | Metal |
- Typical termination in <3 min
- Low insertion loss connection
- Higher fiber retention than mechanical connectors
- No curing oven or proprietary tool required
- Compatible with MOS, QuickPort®, SDX and LightSpace® adapter plates
- Supports 900 um buffered fiber or 3 mm jacketed fiber
- High cable retention crimp for jacketed fiber
- Most robust connection
- 55 dB return loss
- -40 to 85 deg C temperature rating
- -40 to 85 deg C operating temperature
- 0.2 dB typical <0.3 dB max insertion loss, >55 dB return loss
- 0.32 in H x 2.53 in W
- ANSI/TIA-568-C.3/604-2|GR-326|ISI 9001 Certified
- Commercial, Inside and Outside Plant Applications
