Sku #07847700890
MFG #5280-IGO
Attributes
| Type: | Type 3 2-Pole 3-Wire Isolated Ground |
| Voltage Rating: | 125 V AC |
| Frequency Rating: | 50/60 Hz |
| Series: | Industrial |
| Amperage Rating: | 15 A |
| Short Circuit Current Rating: | 5 kA |
- Used to protect sensitive electronic equipment in commercial, industrial and residential locations
- Tamper resistant shutter mechanism prevents incidental contact with energized contacts
- Indicator light provides visual indication that equipment is being protected
- EMI/RFI noise filtering
- Wide variety of color options aid in identifying different types of equipment or applications
- Point of use protection for up to 18000 A of surge current total
- Back and side wired design with durable metal mounting strap
- Single, duplex and 4-in-1 versions
- Rated at NEMA 5-15R
- Withstands 2000 VAC per UL498 dielectric voltage
- Maximum 30 deg C after 250 cycles OL at 200% rated current temperature rise
- Rated V-2 per UL94 flammability
- Brass-hot, green-ground, silver-neutral terminal ID
- 14 to 10 AWG terminal accommodation
- Solid or stranded building wire
- Ratings are permanently marked on device
- Back and side 8 hole feed-thru wired
- Brass 8-32 grounding screw, plated brass terminal screws, thermoplastic nylon face and body material
- Galvanized steel strap and clamp nuts
- Brass isolated ground system
- Phosphor bronze line contacts
- https://www.youtube.com/embed/iYF5b1yuesM
- ANSI C73|NOM 057|NEMA WD1/WD6|UL 498/1449|CSA C22.2|UL94 V-2 Flammability Rating|UL 498/E13399 Listed|UL Fed Spec WC-596 File E13399
