Sku #07498310737
MFG #HST1.5-48-5Y
Attributes
| Type: | VW-1 Adhesive Lined Cross Linked Flame-Retardant Standard |
| Voltage Rating: | 600 V AC |
| Inner Diameter Recovered: | 1/2 in |
| Series: | HST |
| Inner Diameter Expanded: | 1-1/2 in |
| Wall Type: | Thick |
- For wet locations, insulating, protecting wires and cables, for direct burial, outdoor and direct sunlight applications
- Adhesive lined inner wall shall seal and protect against moisture
- The heat shrink tube shall be suitable for direct burial according to UL 486D
- Outer wall flame-retardant
- VW-1 flammability rating
- Adhesive lined black cross linked polyolefin
- High impact and abrasion resistance
- Resistant to splitting or rupture during installation
- Allows optimal sizing for application requirements to provide a lower installed cost and the flexibility to protect different size electrical and electronic components, cables, terminals and connectors
- Suitable for use in 600 VAC applications to comply with UL standards
- 10 years shelf life
- https://www.panduit.com/content/dam/panduit/en/products/media/1/91/991/4991/110524991.mp4
- AMS-DTL-23053/15 Class 1/3 Military Specifications|ARRA Compliant|Buy American Act Compliant|CSA Certified File No. 244528|RoHS Compliant|UL 224|VW-1 Flammability Rated|UL Listed File No. E342365/E173379|CSA File No. 244528|Military Specification SAE-AMS-DTL-23053/15 Class 1|UL 224 VW-1 Flammability Rated|UL 486D File No. E173379/E342365
