Sku #07498310708
MFG #HST0.4-3-QY
Attributes
| Type: | VW-1 Adhesive Lined Cross Linked Flame-Retardant |
| Voltage Rating: | 600 V AC |
| Inner Diameter Recovered: | 0.16 in |
| Series: | HST |
| Inner Diameter Expanded: | 0.4 in |
| Wall Type: | Thick |
- For wet locations, outdoor, direct sunlight and direct burial, insulating, protecting wires and cables
- High impact and abrasion resistance
- Resistant to splitting or rupture during installation
- Variety of diameters
- Convenient packaging
- Quality materials, durability and time tested design
- Thick wall polyolefin heat shrink with a 3:1 ratio shall be used to insulate, seal and protect electrical splices and terminations where maximum flame-retardant and exceptional insulating and sealing characteristics are required
- The adhesive lined inner wall shall seal and protect against moisture
- Irradiated cross linked polyolefin outer wall with an inner wall of hot melt adhesive material
- Highly flame-retardant and sunlight-resistant
- High impact and abrasion resistance
- Resistant to splitting or rupture during installation
- Allows optimal sizing for application requirements to provide a lower installed cost and the flexibility to protect different size electrical and electronic components, cables, terminals and connectors
- https://www.panduit.com/content/dam/panduit/en/products/media/1/91/991/4991/110524991.mp4
- ARRA Compliant|Buy American Act Compliant|CSA Certified File No. 244528|RoHS Compliant|SAE AMS-DTL-23053/15 Class 1 Military Specifications|UL 224|VW-1 Flammability Rated|UL 486D|UL Listed File No. E173379/E342365|UL 486D File No. E173379/E342365|CSA File No. 244528|Military Specification SAE-AMS-DTL-23053/15 Class 1|UL224 VW-1 Flammability Rating
