Sku #04613557356
MFG #OTI55W1202772A0DIM1J/57356
Attributes
| Type: | Compact Constant Current Dimmable Programmable |
| Output Voltage: | 10 to 55 V DC |
| Amperage Rating: | 2 A |
| Input Voltage: | 120 to 277 V AC |
| Power Rating: | 55 W |
| Power Factor: | >0.9 |
- Custom programmable with 1 mA resolution to perfectly match LED load and maximize performance
- Programming does not require powering up or connecting the power supply to AC line voltage
- Integrated OEM programmable features include - constant lumen maintenance, end-of-life indication, LED thermal protection, soft start, dim-to-off
- UL class 2 output for safe operation
- 0.6 A at 120 VAC/0.26 A at 277 VAC input, 700 to 2000 mA at 10 to 55 VDC output
- Protection against line voltage on 0 to 10 V dimming wires
- Architectural grade features include true 1% dimming, synchronized On/Off and dimming control, DIM-to-Off, dimming interface protection
- Wide output current and voltage range
- https://youtu.be/8VTVA15A5_Y
- Architectural, Downlights, In-Grade Fixtures, Recessed Troffer and Wall Washing
- CA Title 24 Compliant|NOM Certified|CA T-24|CSA Certified|cULus Listed|EMI Compliant|IP20 Rated|NEMA SSL1|NOM 47 CFR Part 15 Class A|RoHS Compliant|UL 60730-1 File No. E320395
