ABB 1SVR730824R9300 CM-S Universal 3-Phase Multi-Function Monitoring Relay, 200 to 500 V AC, 2 to 4 A, 2CO DPDT Contact, 200 to 500 V AC V Coil
Sku #01677985194
MFG #1SVR730824R9300
Attributes
| Type: | Universal 3-Phase Multi-Function |
| Voltage Rating: | 200 to 500 V AC |
| Frequency Rating: | 50/60 Hz |
| Series: | CM-S |
| Amperage Rating: | 2 to 4 A |
| Coil Voltage: | 200 to 500 V AC |
- CE Certified|CB Certified|CCC Certified|cULus Listed|DNV GL Approved|EAC Certified|RMRS Certified|RoHS Compliant|RoHS 2011/65/EU|CAN/CSA C22.2 No. 14|EN 50581|IEC/EN 61000-6-2, 61000-6-3|UL 508|CB Certified|CCC Certified|cULus 508 20120829-E140448|CE Certified|DNV GL Certified|EAC Certified|RMRS Approved
- Fixed 0.5 s start up delay
- LED's for the indication of operational states
- Phase sequence monitoring
- Suitable for railway applications
- Over and under voltage monitoring
- Dual frequency measuring 50/60 Hz
- 4 A at 230 VAC rated operational current AC-12
- Powered by the measuring circuit
- Adjustable phase unbalance threshold value
- Adjustable ON-delay/OFF-delay time
- Wide range operating voltage guarantees worldwide operation
- Phase failure detection
- For phase reversal applications (may detect phase loss)
